AWC7813 motion controller user manual
【Pause】icon after pressing the key.
3.2.10 Pause
Figure3-2-10 Pause
The icon is displayed when the machine is working. In the Figure3-1-1 Main
interface 1, click【Pause】button, the machine pauses and maintains its current state.
After pressing this button, except for the 【Stop】key, all the other keys cannot be
used. Press this key to set the speed and power of the file being processed. For
details, please refer to3.9.2 Modify the speed of the file being processed 、 3.10.2
Modify the power of the file being processed。
3.2.11 Interface switching
Figure3-2-11 Interface switching icon
In the main interface, press this key to switch Figure3-1-1 Main interface 1 and
Figure3-1-2 Main interface 2.
3.3 Direction key area
It is mainly used to control the up and down movement of X-axis, Y-axis and
Z-axis, and switch between fast and slow movement. For details, please refer to
