Trocen AWC7813 - Function Key Area; Reset

AWC7813 motion controller user manual
WWW.SZTROCEN.COM
23
Figure3-1-3 Main interface area division
3.2 Function key area
Function key is a key designed to directly realize a specific operation function. It
has the characteristics of simple and clear function orientation and simple and
intuitive operation.
3.2.1 Reset
Figure3-2-1 Reset
Graphic display area
Processing time
display area
Coordinate display
area
Processing file name display area
Counting area
Speed area
Power area
Direction key area
Function key area
Status display area
