Trocen AWC7813 - Page 17

AWC7813 motion controller user manual
WWW.SZTROCEN.COM
7
Wiring board
(1 piece)
AWC7813 Wiring board (base plate)
USB cable
(1 piece/3m)
used by the computer to load files to the
panel
cable
(1 piece/5m)
used by the computer to load files to the
panel
CN Cable
(1piece/1.6m)
Connect the CN1 port of the panel and
wiring board
USB extension
cable
(1piece/0.5m)
Network
extension
cord
(1piece/0.5m)
Screw
(2pcs)
Used to fix the panel
