TSC TTP-244 Plus Programming Manual

TSC AUTO ID Technology Co., Ltd. 70 Copyright 2013 All Rights Reserved.
RSS 410,10,"UPCE",0,2,2,"001220000456|ABCDEFG"
PRINT 1
SIZE 4,1
GAP 0,0
DIRECTION 1
CLS
REM UPCE Rule 2: 00abc00000ij = abcij3
RSS 10,10,"UPCE",0,2,2,"001230000045|ABCDEFG"
PRINT 1
SIZE 4,1
CLS
REM UPCE Rule 3: 00abcd00000j = abcdj4
RSS 10,10,"UPCE",0,2,2,"001234000005|ABCDEFG"
PRINT 1
SIZE 4,1
GAP 0,0
DIRECTION 1
CLS
REM UPCE Rule 4: 00abcde0000j = abcdej where j = 5-9
RSS 10,10,"UPCE",0,2,2,"001234500005|ABCDEFG"
RSS 160,10,"UPCE",0,2,2,"001234500006|ABCDEFG"
RSS 310,10,"UPCE",0,2,2,"001234500007|ABCDEFG"
RSS 460,10,"UPCE",0,2,2,"001234500008|ABCDEFG"
RSS 610,10,"UPCE",0,2,2,"001234500009|ABCDEFG"
PRINT 1
Example of barcode height of EAN8 EAN13 UPCA and UPCE.
SIZE 4,2
GAP 0,0
DIRECTION 1
CLS
RSS 10,10,"EAN8",0,1,1,"1234567|ABCDEFG"
RSS 210,10,"EAN8",0,2,1,"1234567|ABCDEFG"
RSS 410,10,"EAN8",0,3,1,"1234567|ABCDEFG"
PRINT 1
SIZE 4,2
GAP 0,0
DIRECTION 1
CLS
RSS 10,10,"EAN13",0,1,1,"123456789012|ABCDEFG"
RSS 210,10,"EAN13",0,2,1,"123456789012|ABCDEFG"
RSS 410,10,"EAN13",0,3,1,"123456789012|ABCDEFG"
PRINT 1
SIZE 4,2
GAP 0,0
DIRECTION 1
CLS
RSS 10,10,"UPCA",0,1,1,"12345678901|ABCDEFG"
RSS 210,10,"UPCA",0,2,1,"12345678901|ABCDEFG"
RSS 410,10,"UPCA",0,3,1,"12345678901|ABCDEFG"

TSC TTP-244 Plus Specifications

General

Resolution	203 dpi
Print Speed	4 ips
Print Method	Thermal Transfer / Direct Thermal
Weight	2.5 kg
Max. Print Width	4.25 inches
Max. Print Length	90 inches
Processor	32-bit RISC CPU
Interface	RS-232
Label Width	1 inch to 4.4 inches
Power Supply	100-240V AC, 50/60Hz
Operating Temperature	5°C to 40°C
Storage Temperature	-40°C to 60°C
Humidity	25% to 85% non-condensing
Label Thickness	0.06 ~ 0.19 mm (2.36 ~ 7.48 mil)
Dimensions	232 mm (W) x 156 mm (H) x 288 mm (D)
