Phone Jack: 3.5mm (1/8 in.) Stereo Type
Ext.SP Jack: 3.5mm (1/8 in.) Monaural Type
REC.Out Jack: 3.5mm (1/8 in.) Stereo Type
Ext. DC Power and Orange Wire Jack 3 pin (Center Orange
Wire)
DC Power Jack: 5.5mm (1/5 in.) (Center Positive)
GPS/Remote Interface Jack: D Sub 9pin Male Type
Remote Interfase Jack (front panel): 4-pin Mini Custom Type
Internal Speaker
8.0Ω 5.0W Max. 77mm (3.0 in.)
Power Requirements DC:11V to 16.6V(Ext.DC Power Jack or DC Power Jack)
AC Adapter (13.8V DC 750mA Regulated) (AD-1009)
Operating
Temperature
Nominal: -20°C to +60°C -4°F to +140°F
Close Call: -10°C to +60°C +14°F to +140°F
Size 7.2 in.(W) x 5.9 in.(D) x 2.2 in.(H)
Weight 3.42 lbs
Remote Functions Direct PC control
Database management
Wired cloning
Display 64 x 128 Full Dot Matrix LCD with Orange-color back light
