Uniden BCD396XT User Manual

EditBandPlan < UnidenMan4 < TWiki
Set Spacing
Select the number of kHz between each channel. Your options are:
5.00 6.25 10.00 12.50 15.00 18.75 20.00 25.00
30.00 31.25 35.00 37.50 40.00 43.75 45.00 50.00
55.00 56.25 60.00 62.50 65.00 68.75 70.00 75.00
80.00 81.25 85.00 87.50 90.00 93.75 95.00 100.00
Rebanded Motorola Systems
When you create a system that has been rebanded to use the frequencies newly added for
use by the FCC, you have the option now of selecting 800MHz Custom as the Motorola
system type.
Once you create the system, you can set the custom band plan as follows:
1. Edit System Option --> Edit Band Plan
2. Select the band plan entry to edit.
3. Set each of the following entries for the band plan:
a. Set Base Freq (Lower and Upper)
b. Set Offset
c. Set Spacing
For standard rebanded systems, you need to set Band Plan 1 and Band Plan 2 as:
Band Plan Base Freq (Lower) Base Freq (Upper) Offset Polarity Spacing
1 851.025MHz 854.000MHz 440 + 25 kHz
2 851.0125MHz 868.9875MHz 0 + 25 kHz
file:///C|/Documents%20and%20Settings/POpitz/My%20Documents/temp/CDImage_090515/Manual/EditBandPlan.html (2 of 3)5/26/2009 11:15:05 AM
