Uniden BCD396XT User Manual

Thursday, May 14, 2009
106
Digital AGC
This menu lets you set the following items.
Response Time
Reference Gain
In this menu, you can set the Reference Gain for Digital AGC.
Selectable values are from –5 to +5, by steps of 1.
Press [E / yes / gps] to accept the selection and return to the previous menu.
Press [E / yes / gps] to enter each setting.
Response Time
In this menu, you can set the Response Time for Digital AGC.
Selectable values are from –8 to +8, by steps of 1.
Press [E / yes / gps] to accept the selection and return to the previous menu.
Reference Gain
In this menu, you can set the Reference Gain for Digital AGC.
Selectable values are from –5 to +5, by steps of 1.
Press [E / yes / gps] to accept the selection and return to the previous menu.
Adjust Contrast
This function sets the contrast of the display from “Contrast 1” to “Contrast 15”.
Press [E / yes / gps] to accept the selection and return to the previous menu.
Set C-CH Output
The scanner can output the data stream on control channel by using this function.
Off data stream is not outputted
On data stream is outputted
Extend data stream and description are outputted
Press [E / yes / gps] to accept the data and return to the previous menu.
(See Control Channel Data Stream Output for detail)
If the baud rate is slow, the scanner cannot output all data streams. Therefore it is recommended you use
a baud rate of 115200 bps.

Uniden BCD396XT Specifications

General

Belt clip	Yes

Weight and Dimensions

Weight	907 g
Dimensions (WxDxH)	51 x 25 x 1152 mm
