GPS/Remote Interface Jack: 4pin Mini Type
Internal Speaker
24Ω, 0.8 W Max.(1.26 in.)
Power Requirements 3 x AA Size Rechargeable Ni-MH Batteries (1800mAh)
3 x AA Size Alkaline Batteries
AC Adapter (6V DC 800mA Regulated) (AD-1001)
Operating
Temperature
Nominal: -20°C to +60°C -4°F to +140°F
Close Call: -10°C to +60°C +14°F to +140°F
Size 2.40 in.(W) x 1.22 in.(D) x 5.35 in.(H) (Without
Antenna)
Weight 0.37 lbs (Without Battery and Antenna)
Remote Functions Direct PC control
Database management
Wired cloning
Display 64 x 128 Full Dot Matrix LCD with orange back light
Sensitivity (nominal) 12dB SINAD
0.4•V 25–27.995 MHz AM
0.3•V 28–53.98 MHz NFM
0.5•V 54–71.95 MHz WFM
0.2•V 72–75.995 MHz FM
