Uniden BCD396XT User Manual

EditSite < UnidenMan4 < TWiki
Auto The scanner uses the default modulation type for this frequency's
band.
NFM The scanner treats the frequency as a Narrowband FM band.
FM The scanner treats the frequency as an FM band.
Set Attenuator
Turn on attenuation to reduce the signal strength by 20 dB. You can turn on attentuation
for individual frequencies and channels or for entire sites. If you turn on attenuation for a
site, all frequencies within that site will be attenuated.
Set Lockout
Decide whether you want to lock out the site so the scanner will ignore it during Scan
and Search modes. Choose one of the following options:
● Unlocked: The site is not locked out.
● Temporary L/O: The site is locked out until you turn the scanner off and back on.
● Lockout: The site is permanently locked out.
Set Hold Time
Set the minimum number of seconds the scanner should spend checking this system or
site even if there is no traffic on any channel. (The scanner always checks each channel
in a system or site once even if the hold time is set to 0 seconds.) Select the number of
seconds from 0 through 255 (0 is the default).
Set LocationInfo
Use this menu to program location information for this site.
Set State (BCT15X Only)
Sets the U.S. State or Canadian Province associated with the system. If selected, the
system will be unlocked when you set the scanner to the state and locked out when you
file:///C|/Documents%20and%20Settings/POpitz/My%20Documents/temp/CDImage_090515/Manual/EditSite.html (3 of 5)5/26/2009 11:14:48 AM

Uniden BCD396XT Specifications

General

Belt clip	Yes

Weight and Dimensions

Weight	907 g
Dimensions (WxDxH)	51 x 25 x 1152 mm
