Vaisala HMT370EX User Manual

R1/2”ISO7/1 or NPT1/2”
Ø 13.5 (0.53)
35 (1.37)
Ø 12 (0.47)
14 (0.55)
35 - 157/379 (1.37 - 6.2/14.9) (user adjustable)
188/410 (7.40/16.1)
226/448 (8.90/17.6)
Length for standard/optional probes
Figure 73 Dimensions in mm (inches)
13.8
Spare parts and accessories
Information on spare parts, accessories, and calibration products is available
online at www.vaisala.com and store.vaisala.com.
Table 51 Accessory availability
Accessory Part number Models
Probe accessories
M12 Indigo USB Adapter cable
accessory for connecting HMT370EX
probes to Insight
USB2 All models
Ball valve ISO 1/2 with welding joint
• Pressure range at +20 °C (+68 °F)
0 … 20 bar (0 … 290 psia) (during
installation max. 10 bar (145 psia)
BALLVALVE-1 HMP378
Duct installation kit 210697 HMP373, HMP377
Mounting flange 210696 HMP375
Cable gland M20 x 1.5 with split seal HMP247CG HMP373, HMP375, HMP377
Fitting body M22 x 1.5 17223SP HMP374
Fitting body NPT1/2 17225SP HMP374
Fitting body ISO1/2 solid structure DRW212076SP HMP378
Fitting body NPT1/2 solid structure 212810SP HMP378
Chapter 13 – Technical data
141
