Note: The WRI400 will send a tamper signal while the cover is off.
3 Log in to the SUS software (refer to the SUS User Guide for log-in procedure).
Note: Make sure the HHD connection type is set to USB Connection.
4 Connect the HHD to the WRI400 USB port (J5). The WRI400's USB LED (2) will blink green.
The WRI400 is communicating with the HHD when the USB LED blinks green and the HHD display
indicates WRI400 at the bottom of the main screen. The SUS is now ready to view the WRI400
settings.
5 To Edit Settings or Update Firmware on the WRI400, the SUS software and the WRI400 must be coupled.
Follow the steps below to couple the WRI400 and the HHD.
Coupling with the HHD
1 Connect the WRI400 to the HHD (see section above for details).
2 On the WRI400, press and hold the SCHLAGE button while pressing the LINK button three (3) times
within 5 seconds. The USB LED will blink red and green.
3 On the SUS, select the option Couple HHD to Device. The SUS will report when coupling is successful.
Successful coupling will be indicated on the WRI400 with a blinking green USB LED.
Linking to a PIM400
1 Click Start on the HHD. A Menu will open with a list of programs.
2 Select the Schlage Utility Software option to open SUS.
3 Select Manager from the Log on as drop down menu.
4 Enter the password into the Password field. Default password is 123456
5 Click the Login button. The SUS program will open. The bottom of the screen will say No Device
Connected.
6 Connect the HHD to the WRI400 using the supplied USB cable (see instruction above for details on
connecting the WRI400 to the HHD).
