Vanderbilt lite blue User Manual

22 lite blue Installation Manual
lite blue Pin Layout
lite blue Pin Functions
TB1: Power input for lite blue. 12VDC or 24VDC.
 GND (-)  Shutdown / Restart
 FLT (+)  Shutdown / Restart
 GND (-)  Tamper
 TMP (+)  Tamper
 GND is (-)  VLB Main Power
 VIN is (+)  VLB Main Power

Vanderbilt lite blue Specifications

General

Brand	Vanderbilt
Model	lite blue
Category	Controller
Language	English
