66 lite blue Installation Manual
Proximity Read Head Pin Connections
SBB-RI
Proximity Reader
PIN 1 (CLK)
DATA 0 (GREEN)
Pin 2 (DAT)
DATA 1 (WHITE)
Pin 3 (GND)
GROUND (BLACK)
Pin 4 (PWR)
POWER (RED)
Pin 5 (GRN)
LED (ORANGE)
Pin 6 (RED)
NOT USED
Pin 7 (BUZ)
NOT USED
Magnetic Stripe Reader
Magnetic Stripe Read Head Pin Connections
SBB-RI
Magnetic Stripe Reader
PIN 1 (CLK)
DATA 0 (WHITE)
Pin 2 (DAT)
DATA 1 (GREEN)
Pin 3 (GND)
GROUND (BLACK)
Pin 4 (PWR)
POWER (RED)
Pin 5 (GRN)
LED (ORANGE)
Pin 6 (RED)
NOT USED
Pin 7 (BUZ)
NOT USED
