68 lite blue Installation Manual
Highlights
 Supports various read head technologies; Proximity, (Wiegand Format) and Magnetic Stripe
 Standard 26-bit
 Vanderbilt 34-bit
 Xceed-ID XF1050 Reader
 HID Corporate 1000 35-Bit (not evaluated by UL)
 HID Corporate 1000 48-Bit (not evaluated by UL)
 HID/ProxIF 37-Bit
 XceedID 40-Bit
 Vanderbilt 35-bit (including EV1)
 MiFare 32-Bit Serial Number
 Communicates via network protocol at 10Base-T
 Powered locally by a UL294 Listed Power-Limited, Power Supply capable of 4 hours standby power.
 OPTIONAL - can be powered directly from lite blue. (See Cable Requirement Chart for details)
Standard Features
 Supports one read-head credential
 Communicates with lite blue via network protocol at 10/100 Base-T
 Connection for one multi-color LED for access granted or access denied indication
 Includes 4 input contacts for devices such as exit request (REX), door position switch (DOD), etc.
Specifications
 Board Dimensions - 3-13/16” x 3-13/16” x 2-1/4”D
 Enclosure Dimensions - 8-1/4”H x 7-1/2W” x 3-1/2”D
 Power requirements - 20VDC to 32VDC
 Power consumption - 300mA max. with reader
 Ambient temperature - 0º to 49º C or 32º to 120º F
VBB-NRI Enclosure
VBB-NRI Enclosure - An enclosure with a hinged door is included for each VBB-NRI.
Features
 Metal enclosure with hinged door
 Enclosure Dimensions: 8.25” x 7.5” x 3.5”
