Vanderbilt lite blue User Manual

VLBIM06/15/15 v4.1.0
Chapter 1 lite blue 19
Highlights
 8 card reader maximum configuration
 8 per RS-485 data channel maximum
 2 per onboard Wiegand channels maximum
 Each RS-485 channel divided into two sections
 Lockable tamper proof enclosure
 256MB NAND Flash and 128MB SDRAM with 5,000 ID capability
 Dynamically allocated memory
 A 8G memory min-SD Card
 10/100 Base-T Ethernet Connection
 Linux Kernel operating system
Dimensions
 lite blue controller: 8" h x 6" w
 Enclosure: 12" h x 10" w x 2.75" d
 Power: 12/24 VDC
 Power Consumption: 250mA
 Max. Device Output: 24VDC @100mA (max. 800mA per power input row)
 Ambient Temperature: 0C to 49C or 32F to 120F
 Humidity: - 85%, +/- 5%
Power Supply Requirements
 UL294 Listed Power-Limited Power Supply capable of 4 hours standby power providing 12VDC or 24VDC
Note: The LED on the cover of the VLB is a power indicator. However it is not an AC indicator as the UL Listed
power-limited power supply capable of 4 hour standby power could be providing the VLB with power even if AC
power has been removed.
The lite blue controller is designed to only provide power the power supply to readers attached to the two
onboard reader interfaces. Additional devices must be powered independently from the lite blue controller. If a
single power supply is used, it must be large enough to power the lite blue controller and all attached devices.
Make sure that the total power requirements for all devices does not exceed the output of the power supply(s) in
use (see specific device chapters for power requirements). If not enough power is being supplied, the devices and
the lite blue controller will not work correctly.
