118 lite blue Installation Manual
 Remote antenna modules - The PIM-SBB is capable of accommodating Remote Antenna Modules
Specifications for the PIM-SBB
 RS-485 Communication to lite blue controller
 Supports 16 Wireless Devices
 No VBB-RI is required
 lite blue can support multiple PIM-SBB
Schlage Wireless Modules
There are several types of WAPM modules such as the WA series of locks and the WRI. The following sections
detail each one of these modules.
WA Series Locks (WA)
The WA series locks are products in the Schlage Wireless Access Point Module (WAPM) category. They contain
all of the elements needed to electronically control and monitor access through a door via an RF link. The lock
includes a lockset, a Request-to-Exit sensor/switch, an optional Request-to-Enter sensor/ switch, a power supply
(battery pack), and terminals for monitoring a door position switch/sensor, a card reader, and an RF transceiver for
communicating with another RF transceiver in a Panel Interface Module (PIM) which interfaces with lite blue.
Performance
 Verification Time: Typically 0.2 seconds including lock actuation time but not including access panel delays
 Communications (Heartbeat) Interval - Configurable in 15 second increments from 15 seconds to 273 hours
 Addressing - Automatic during Linking
Card reader - Magnetic Stripe Card Reader
 ANSI/BHMA A156.25 compliant Track 2 Clock & Data Output (Some card code conversions available)
 Read Rate - 3 – 50 inches per second
 Card Thickness - 0.030 inches thick
 ANSI/ISO Standards 7810, 7811 1/51 7812, and 7813
 Indoor only
Card Reader - Proximity Reader
 ANSI/BHMA A156.25 compliant
 Compatible with HID proximity cards
 Wiegand output
 Weatherproof bezel and gasket provide protection for outdoor use.
 Card Read Range: up to 4 inches
 Compliance to FCC Part 15, RSS-210 of Industry Canada
 ESD Protection: 12KV
