Before Installation 15
Environmental Consideration
 lite blue (VLB), the VBB-NRI and the VBB-RI must be installed indoors within the protected premises in a
clean and a dust free environment.
 Ambient temperature: 32F to 120F (0 C to 49C)
 Relative Humidity: 85%, +/- 5%
Cable Requirement Chart
The chart below gives the recommended distance between the lite blue controller and the devices it connects to.
All cabling and wire should be UL Listed and/or Recognized wire suitable for the application.
 Power supply input line transient protection complying with the Standard for Transient Voltage Surge
Suppressors, UL 1449, with a maximum marked rating of 330 V.
 RS-485 communication line(s) must have signal line transient protection complying with the Standard for
Protectors for Data Communications & Fire Alarm Circuits, UL 497B, with a standard marked rating of 50 V.
Connection
Max Distance
Power (ft)
Max Distance
Communication (ft)
Cable Requirement
lite blue to VBB-RI
4000
4000
18 AWG/2 Pair, Strd, Twst, Shld
VBB-OBRI to Magstripe Reader Head
200
200
22 AWG/5 Condr, Strd, Shld
VBB-OBRI to Proximity Reader Head
500
500
22 AWG/5 Condr, Strd, Shld
VBB-NRI to Power Supply
4000
N/A
18 AWG/2 Pair, Strd, Twst, Shld
lite blue to AD-300
4000
4000
18 AWG/2 Pair, Strd, Twst, Shld
lite blue to Schlage VIP
At 12 Volts DC
1000
4000
18 AWG/2 Pair, Strd, Twst, Shld
At 24 Volts DC
3000
4000
18 AWG/2 Pair, Strd, Twst, Shld
lite blue to PIM400-485-VBB
4000
4000
18 AWG/2 Pair, Strd, Twst, Shld
lite blue to PIM-SBB (Legacy)
1000
1000
18 AWG/2 Pair, Strd, Twst, Shld
Abbreviations:
 Strd. = Stranded
 Shld. = Shielded
 Twst. = Twisted
