130 lite blue Installation Manual
6 Generate a transaction by presenting any card to the reader or by pushing the tamper button. The
transaction will display on the CDT software screen. This indicates that the lock has been addressed (see
figure below).
7 Click on the Configuration tab. This tab is used to set the Heartbeat / First / Delay / Retry / FC Mode or Card
Number Mode.
a) The Heart Beat is used to determine how often the lock communicates with the PIM. Leave this at
default.
b) Set the First / Delay to 300. This is required for proper operation.
c) Set the Retry to 7. This is required for proper operation.
8 Click on the Set button at the bottom of the CDT screen.
Note: A transaction may need to be produced in order for these settings to be sent to the lock.
9 Make a note of the address as this will be used by the lite blue user interface to configure the lock.
10 Configuration of the lock is complete. To set up another WA series lock, follow steps 1 through 9 above.
