Smart Plus (PHT-35LHS)
Technical Manual
VT-TECH-Smart Plus-001
94 / 188
COPYRIGHT© 2018 VATECH.
ALL RIGHTS RESERVED
4) Make the PHANTOM JIG ASS’Y level by using BUBBLE LEVEL and three ALIGN PINs.
5) Put the UNIFORMITY CHECK PHANTOM on the PHANTOM JIG ASS’Y.
6) Put the M&R CHECK PHANTOM on the UNIFORMITY CHECK PHANTOM.
BUBBLE LEVEL
ALIGN PIN
ID Number
UNIFORMITY CHECK PHANTOM
ID Number
UNIFORMITY CHECK PHANTOM
M&R CHECK PHANTOM
