55-6 Supplemental Operations D7x11 Series II Navigator Directional Drill
(3) Hydraulic Control Lever
Left . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .extend cylinder
Middle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . lock hydraulics
Right . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . retract cylinder
(4) Hand Lever
Push down . . . . . . . . . . . . . . . . . . . . . . . . pumps hydraulic fluid
Pull up. . . . . . . . . . . . . . . . . . . . . . . . . . . . draws fluid into pump
(5) Chain Adjustment Nut
Clockwise . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . tighten chain
Counterclockwise . . . . . . . . . . . . . . . . . . . . . . . . . . . loosen chain
3
4
5
