D7x11 Series II Navigator Directional Drill Controls 20-5
REMOTE LOCKOUT BATTERY CHARGER
(1) Battery Charger
Insert remote transmitter battery into charger.
Amber light (A), located on the charger, flashes when battery is fully
charged. Green light (B) indicates charger is receiving power.
(2) Battery Charger Outlet
Ensure charger plug is fully inserted into outlet.
(3) Remote Lockout Transmitter Storage
NOTE: Transmitter storage for machine serial numbers 494–496 is
inside the engine compartment, under the hood (D). Use bar (E) with
keeper pin (F), to hold transmitter in place.
A
B
1
2
D
E
F
3
