Vermeer Navigator D7 11 Series User Manual

20-10 Controls D7x11 Series II Navigator Directional Drill
Transport Station Controls
TRACK/GROUND DRIVE CONTROLS
(1) Left Track
Push . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . move forward
Pull. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . move backward
(2) Right Track
Push . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . move forward
Pull. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . move backward
Push one lever ahead and pull other lever back to counter-rotate tracks.
The levers will self-center when released.
NOTE: Ground drive controls do not function with an operator in the seat.
1
2
4_00
