30-26 Overview D7x11 Series II Navigator Directional Drill
Locator System
The ability to locate the drill head is paramount to the success of any bore. Failure to use proper locating
techniques can result in the drill head becoming lost, coming out in the wrong location, or missing the intended
target altogether. Refer to the Fundamentals of HDD Manual for information on locator systems.
Rod Loading
ROD BOX - LOAD
Remove pins (1) from each end of rod box, and fold top cover open, to manually remove
or return rods to rod box. Load rods with male threads to the front.
Close rod box cover and insert keeper pins (1) to contain rods in box during transport.
1
