D7x11 Series II Navigator Directional Drill Supplemental Operations 55-5
PORTABLE BREAKOUT CONTROLS
(1) Pressure Gauge
Gauge displays hydraulic pressure as handle is pumped.
(2) Hydraulic Oil Fill/Drain/Breather Fitting . . . fill/drain hydraulic oil
NOTE: For replacement oil, use an ISO 10 or ISO 22 oil.
1
2
