D7x11 Series II Navigator Directional Drill Overview 30-5
Remote Lockout - Engine Shutdown Test
The Remote Lockout system is equipped to operate as either a hydraulic lockout (default)
or an engine shutdown system. Refer to “Hydraulic Lockout or Engine Shutdown Option,”
page 30-6.
Step 1: Start machine and remain in operator’s seat.
Step 2: Press and hold black Power On/Off Button (1) for two seconds.
Step 3: Press and hold green Run Button (3) for two seconds. Green light will
illuminate.
NOTE: Machine is now in Drill mode.
Step 4: Test thrust and rotation controls. They should work.
Step 5: Press and hold red Lockout Button (2) for two seconds. Red light will illuminate. Machine is now in
Lockout mode, and engine must shut down. If engine does not shut down, contact your Vermeer
dealer immediately.
After successful Lockout test, press and hold the green button (3) for two seconds to return to Drill mode.
IMPORTANT: Perform Remote Lockout Test before drilling each day.
1
2 3
4_00
