D7x11 Series II Navigator Directional Drill Overview 30-9
RADIO CHANNEL - CHANGE
When operating two machines in close proximity, communication may be affected. Changing radio channels will
correct this problem. Changing radio channel is possible only when remote is communicating with machine
(yellow light is not flashing). With remote transmitter near the machine, push and hold black Power ON/OFF
Button and green RUN Button simultaneously until yellow light flashes. Wait for yellow light to turn off.
Channel is now changed.
BATTERY CONDITION
Low Battery
NOTE: Low battery indication is only displayed on the remote transmitter.
When approximately 10% of battery power is left, blue light (1) will flash.
Discharged Battery
If battery discharges and a loss of signal occurs in RUN mode, drilling will continue
uninterrupted. If battery discharges in LOCKOUT mode, a new battery must be installed and
RUN mode selected before drilling can continue.
Recharge Battery
Install battery in battery charger (2). Ensure charger is plugged in (3). Battery will recharge
even when machine ignition is off. It does not charge when the Battery Disconnect Switch is
OFF. A spare battery may be kept in the charger for use in the event of battery failure.
Amber light on underside of charger will flash when battery is fully charged. Green light in
same location will come on to indicate power to charger.
NOTE: Additional chargers may be purchased from your dealer for charging the battery in an
auxiliary vehicle.
1
2
3
4_00
