General Operation
110 TVM Series Installation and Operation Handbook
Copyright © 2008, Harris Corporation
Figure 3-61. CRC Display Diagram
Table 3-54. Description of the CRC Display Diagram
Field
Identifier
Field Information Nomenclature
1 Input Displays user-configurable source IDs for input and routers
2 Display Label Displayed as CRC DISPLAY
3 Standard Displayed as the line rate/frame rate [1080i/59.94]; when no
signal is present, No Signal appears
4 Reset Information Reset information; press ENT to reset is displayed
5 CRC timer, information
and errors
Lists the CRC information
