Global Setup Menu Functions
TVM Series Installation and Operation Handbook 145
Copyright © 2008, Harris Corporation
Table 4-8. Video Alarms, Digital Menu
Selection Selection Option Selection Option Selection Option
OFF - -
ON - -
LOSS OF CARRIER
DURATION 0 TO 60 Seconds (2
Seconds is Default)
-
OFF (Default) - -
ON - -
LOSS OF
REFERENCE
DURATION 0 TO 60 Seconds (2
Seconds is Default)
-
OFF (Default) - -
ON - -
LOSS OF ACTIVE
VIDEO – DIG
THRESHOLD 0 TO 350 mV (300 mV is
Default)
-
SENSITIVITY 2 TO 20 CES (2 CES is
Default)
-
DURATION 0 TO 60 Seconds (2
Seconds is Default)
-
OFF - ENABLE
ON -
LOSS OF PAYLOAD
IDENTIFIER (OPT
3GB only)
DURATION 0 TO 60 Seconds (2
Seconds is default)
-
OFF (Default) ENABLE
ON
THRESHOLD 650 TO 750 mV (716 mV
is Default)
SENSITIVITY 1 TO 20 CES (15 CES is
Default)
RGB GAMUT UPPER
DURATION 0 TO 60 Seconds (2
Seconds is Default)
ENABLE OFF (Default)
ON
THRESHOLD -50 TO 50 mV (-10 mV is
Default)
SENSITIVITY 1 TO 20 CES (15 CES is
Default)
RGB GAMUT
LOWER
DURATION 0 TO 60 SECONDS (2
Seconds is Default)
OFF (Default) ENABLE
ON
DIGITAL GAMUT
LUMA GAMUT
UPPER
THRESHOLD 525 NTSC IRE:
90 TO 108 IRE
(105 is Default)
