Table 4-8. Video Alarms, Digital Menu
Selection Selection Option Selection Option Selection Option
THRESHOLD 625 PAL UNITS:
92 TO 109 UNITS
(107 UNITS is Default)
PAL mV:
643 TO 762 mV
(750 mV is Default)
SENSITIVITY 1 TO 20 CES (15 CES is
Default)
DURATION 0 TO 60 SECONDS (2
Seconds is Default)
OFF (Default) ENABLE
ON
LUMA GAMUT
LOWER
THRESHOLD 525 NTSC IRE:
1.5 TO 20 IRE
(1.5 is Default)
THRESHOLD 625 PAL UNITS:
-6 TO 20 UNITS
(-4 UNITS is Default)
PAL mV:
-46 TO 143 mV
(-35 mV is Default)
SENSITIVITY 1 TO 20 CES (15 CES is
Default)
DURATION 0 TO 60 SECONDS (2
Seconds is Default)
OFF (Default) ENABLE
ON
THRESHOLD 525 NTSC IRE:
50 TO 140 IRE
(120 is Default)
THRESHOLD 625 PAL UNITS:
51 TO 143 UNITS
(123 UNITS is Default)
PAL mV:
357 TO 1000 mV
(857 mV is Default)
SENSITIVITY 1 TO 20 CES (15 CES is
Default)
PEAK GAMUT
UPPER
DURATION 0 TO 60 SECONDS (2
Seconds is Default)
OFF (Default) ENABLE
ON
PEAK GAMUT
LOWER
THRESHOLD 525 NTSC IRE:
-40 TO 0 IRE
(-20 is Default)
