Global Setup Menu Functions
148 TVM Series Installation and Operation Handbook
Copyright © 2008, Harris Corporation
Table 4-8. Video Alarms, Digital Menu
Selection Selection Option Selection Option Selection Option
OFF (Default) ENABLE
ON
WSS (WIDE
SCREEN
SIGNALING) NOT
DETECTED
DURATION 10 TO 600 SECONDS
(240 SEC is Default)
OFF (Default) ENABLE
ON
XDS NOT
DETECTED
DURATION 10 TO 600 SECONDS
(240 SEC is Default)
OFF (Default) ENABLE
ON
XDS NOT
UPDATING
DURATION 10 TO 600 SECONDS
(240 SEC is Default)
OFF (Default) - ENABLE
ON -
CRC- HD
DURATION 0 TO 60 Seconds (2
Seconds is Default)
-
OFF (Default) - ENABLE
ON -
EDH - SD
DURATION 0 TO 60 Seconds (2
Seconds is Default)
-
ENABLE -
END OF TOP BORDER
525
NTSC LINES:
+21 TO +139
(21 is Default)
TOP BORDER
END OF TOP BORDER
625
PAL LINES:
+19 TO +159
(19 is Default)
ENABLE -
START OF BOTTOM
BORDER 525
NTSC LINES:
+140 TO +262
(140 is Default)
BOTTOM BORDER
START OF BOTTOM
BORDER 625
PAL LINES:
+160 TO +312
(160 is Default)
THRESHOLD 10 TO 350 mV (286 mV
is Default)
-
LETTERBOX - SD
DURATION 0 TO 60 Seconds (2
Seconds is Default)
-
ENABLE - LEFT BORDER
END OF LEFT BORDER +1 TO +860
(1 is Default)
ENABLE -
PILLAR BOX - HD
RIGHT BORDER
START OF RIGHT
BORDER
+861 TO +1920
(1920 is Default)
