Global Setup Menu Functions
TVM Series Installation and Operation Handbook 149
Copyright © 2008, Harris Corporation
Table 4-8. Video Alarms, Digital Menu
Selection Selection Option Selection Option Selection Option
THRESHOLD 10 TO 350 mV (286 mV
is Default)
-
DURATION 0 TO 60 Seconds (2
Seconds is Default)
-
OFF (Default) - ENABLE
ON -
THRESHOLD 0 TO 350 mV (2 mV is
Default)
-
VERTICAL 1 TO 200 LINES (2
LINES is Default)
-
PICTURE SHIFT
HORIZONTAL 1 TO 300 PIXELS (2
PIXELS is Default)
-
OFF (Default) - ENABLE
ON -
EYE JITTER
THRESHOLD SD 100 TO 3700 ps (100 ps
is Default)
-
THRESHOLD HD 50 TO 670 ps (50 ps is
Default)
-
DURATION 0 TO 60 SECONDS (2
Seconds is Default)
-
OFF (Default) - ENABLE
ON -
MICROSECONDS 1 TO 64 (1 µ SECOND is
Default)
-
LINES 0 TO 50 LINE(S) (1 is
Default)
-
TIMING ALARM
DURATION 0 TO 60 SECONDS (2
Seconds is Default)
-
□ Pass □ Fail □ N/A Initia l _____
Table 4-9. Video Alarms, Analog Menu
Selection Selection Option Selection Option Selection Option
ALARM REPORTING
SETUP
MATRIX SCREEN - -
OFF (Default) - FORMAT CHANGE ENABLE
ON -
OFF (Default) - ENABLE
ON -
LOSS OF SIGNAL
DURATION 0 TO 60 SECONDS (2
Seconds is Default)
-
OFF (Default) - ENABLE
ON -
LOSS OF
REFERENCE
DURATION 0 TO 60 SECONDS (2
Seconds is Default)
-
