Global Setup Menu Functions
150 TVM Series Installation and Operation Handbook
Copyright © 2008, Harris Corporation
Table 4-9. Video Alarms, Analog Menu
Selection Selection Option Selection Option Selection Option
OFF (Default) - ENABLE
On -
THRESHOLD NTSC NTSC IRE:
0 TO 50 IRE
(40 is Default)
-
THRESHOLD PAL
• PAL UNITS:
0 TO 51 UNITS
(41 UNITS is
Default)
• PAL mV:
0 TO 357 mV
(287 mV is Default)
-
LOSS OF VIDEO
DURATION 0 TO 60 SECONDS (2
Seconds is Default)
-
OFF (Default) ENABLE
ON
THRESHOLD NTSC NTSC IRE:
50 TO 140 IRE
(120 is Default)
THRESHOLD PAL
• PAL UNITS:
51 TO 143 UNITS
(136 UNITS is
Default)
• PAL mV:
357 TO 1000 mV
(951 mV is Default)
SENSITIVITY 1 TO 20 CES (15 CES is
Default)
ANALOG GAMUT PEAK UPPER
DURATION 0 TO 60 SECONDS (2
Seconds is Default)
OFF (Default) ENABLE
ON
THRESHOLD NTSC NTSC IRE:
-40 TO 0 IRE
(-20 is Default)
THRESHOLD PAL
• PAL UNITS:
-41 TO 0 UNITS
(-34 UNITS is
Default)
• PAL mV:
-285 TO 143 mV
(-238 mV is Default)
SENSITIVITY 1 TO 20 CES (2 CES is
Default)
PEAK LOWER
DURATION 0 TO 60 SECONDS (2
Seconds is Default)
OFF (Default)
ANALOG GAMUT
(CONT)
LUM UPPER ENABLE
ON
