Global Setup Menu Functions
TVM Series Installation and Operation Handbook 151
Copyright © 2008, Harris Corporation
Table 4-9. Video Alarms, Analog Menu
Selection Selection Option Selection Option Selection Option
THRESHOLD NTSC NTSC IRE:
50 TO 140 IRE
(105 is Default)
THRESHOLD PAL
• PAL UNITS:
51 TO 143 UNITS
(107 UNITS is
Default)
• PAL mV:
357 TO 1000 mV
(748 mV is Default)
SENSITIVITY 1 TO 20 CES (18 CES is
Default)
DURATION 0 TO 60 SECONDS (2
Seconds is Default)
OFF (Default) ENABLE
ON
THRESHOLD NTSC NTSC IRE:
-5.0 TO 10 IRE
(-2.5 is Default)
THRESHOLD PAL
• PAL UNITS:
-10 TO 0 UNITS
(-5 UNITS is Default)
• PAL mV:
-70 TO 0 mV
(-35 mV is Default)
SENSITIVITY 1 TO 20 CES (18 CES is
Default)
LUM LOWER
DURATION 0 TO 60 SECONDS (2
Seconds is Default)
OFF (Default) ENABLE
ON
CC NOT DETECTED
– ANL
DURATION 0 TO 600 SECONDS (240
Seconds is Default)
OFF (Default) ENABLE
ON
CC NOT UPDATING
– ANL
DURATION 0 TO 600 SECONDS (240
Seconds is Default)
OFF (Default) ENABLE
ON
TT NOT DETECTED
– ANL
DURATION 0 TO 600 SECONDS (240
Seconds is Default)
OFF (Default) ENABLE
ON
CAPTIONING
TT NOT UPDATING
– ANL
DURATION 0 TO 600 SECONDS (240
Seconds is Default)
