Global Setup Menu Functions
152 TVM Series Installation and Operation Handbook
Copyright © 2008, Harris Corporation
Table 4-9. Video Alarms, Analog Menu
Selection Selection Option Selection Option Selection Option
OFF (Default) ENABLE
ON
XDS NOT DETCTED
– ANL
DURATION 0 TO 600 SECONDS (240
Seconds is Default)
OFF (Default) ENABLE
ON
XDS NOT
UPDATING – ANL
DURATION 0 TO 600 SECONDS (240
Seconds is Default)
OFF (Default) ENABLE
ON
ST NOT UPDATING
– ANL
DURATION 0 TO 600 SECONDS (240
Seconds is Default)
OFF (Default) ENABLE
ON
ST NOT DETECTED
– ANL
DURATION 0 TO 600 SECONDS (240
Seconds is Default)
OFF (Default) ENABLE
ON
H SYNC UPPER
THRESHOLD NTSC NTSC IRE:
-50 TO -42 IRE
(-45 is Default)
THRESHOLD PAL
• PAL UNITS:
-51 TO -46 UNITS
(-46 UNITS is
Default)
• PAL mV:
-356 TO -320 mV
(-320 mV is Default)
H SYNC UPPER
(CONT)
DURATION 0 TO 60 SECONDS (2
Seconds is Default)
OFF (Default) ENABLE
ON
THRESHOLD NTSC NTSC IRE:
-38 TO -20 IRE
(-35 is Default)
THRESHOLD PAL
• PAL UNITS:
-42 TO -20 UNITS
(-36 UNITS is
Default)
• PAL mV:
-292 TO -142 mV
(-252 mV is Default)
H SYNC LOWER
DURATION 0 TO 60 SECONDS (2
Seconds is Default)
SYNC AND BURST
BURST UPPER ENABLE OFF (Default)
