Global Setup Menu Functions
TVM Series Installation and Operation Handbook 153
Copyright © 2008, Harris Corporation
Table 4-9. Video Alarms, Analog Menu
Selection Selection Option Selection Option Selection Option
ON
THRESHOLD NTSC NTSC IRE:
42 TO 50 IRE
(45 is Default)
THRESHOLD PAL
• PAL UNITS:
46 TO 51 UNITS
(46 UNITS is Default)
• PAL mV:
321 TO 357 mV
(322 mV is Default)
DURATION 0 TO 60 SECONDS (2
Seconds is Default)
OFF (Default) ENABLE
ON
THRESHOLD NTSC NTSC IRE:
20 TO 38 IRE
(35 is Default)
THRESHOLD PAL
• PAL UNITS:
20 TO 42 UNITS
(36 UNITS is Default)
• PAL mV:
143 TO 293 mV
(252 mV is Default)
BURST LEVEL
LOWER
DURATION 0 TO 60 SECONDS (2
Seconds is Default)
OFF - ENABLE
ON -
ODD (Default) - FIELD
EVEN -
LINE 1 TO 50 LINE(S) (25
LINES is Default)
-
POSITION 0.0 TO 64.0 µs (49.5
microseconds is the
default)
-
PHASE 0 TO 359.75
DEGREE(S) (283.5 is
Default)
-
RANGE 5 TO 20 DEGREE(S)
(7.5 is Default)
-
BURST/CHROMA
PHASE
DURATION 0 TO 60 SECONDS (2
Seconds is Default)
-
OFF (Default) - - H BLANKING
WIDTH NTSC NTSC µ SECONDS:
8 TO 16 µ SECONDS
(10.9 is Default)
-
