Global Setup Menu Functions
162 TVM Series Installation and Operation Handbook
Copyright © 2008, Harris Corporation
Table 4-16. Communications Setup Menu
Selection Selection Option Selection Option Selection Option
OFF (Default) - TERMINATION
ON -
19200 Baud -
38400 Baud (Default) -
57600 Baud -
RCU PORT
BAUD RATE
115200 Baud -
IP CONFIGURATION ETHERNET CONFIG
SCREEN
- -
SELECT A -
ON AIR A -
SELECT/ON AIR A -
INPUT 1
USER GPI ALARM 1 -
SELECT INPUT B -
ON AIR B -
SELECT/ON AIR B -
INPUT 2
USER GPI ALARM 2 -
SELECT C -
ON AIR C -
SELECT/ON AIR C -
INPUT 3
USER GPI ALARM 3 -
SELECT INPUT D -
ON AIR D -
SELECT/ON AIR D -
INPUT 4
USER GPI ALARM 4 -
RECALL PRESET 1 -
GPI INPUT
FUNCTION
INPUT 5
USER GPI ALARM 5 -
RECALL PRESET 2 - INPUT 6
USER GPI ALARM 6 -
RECALL PRESET 3 - INPUT 7
USER GPI ALARM 7 -
RECALL PRESET 4 - INPUT 8
USER GPI ALARM 8 -
RECALL PRESET 5 -
INPUT 9
USER GPI ALARM 9 -
