Global Setup Menu Functions
TVM Series Installation and Operation Handbook 163
Copyright © 2008, Harris Corporation
Table 4-16. Communications Setup Menu
Selection Selection Option Selection Option Selection Option
NORMALLY OPEN - GPO OUT 1
POLARITY
NORMALLY CLOSED -
NORMALLY OPEN - GPI OUT 2
POLARITY
NORMALLY CLOSED -
FOLLOW INPUT A -
FOLLOW INPUT B -
FOLLOW INPUT C -
FOLLOW INPUT D -
GPI OUT 1 SETUP
FOLLOW ALARMS
(Default)
-
FOLLOW INPUT A -
FOLLOW INPUT B -
FOLLOW INPUT C -
FOLLOW INPUT D -
GPI OUTPUT
FUNCTION
GPI OUT 2 SETUP
FOLLOW ALARMS
(Default)
-
INPUT 1 RENAME SCREEN -
INPUT 2 RENAME SCREEN -
INPUT 3 RENAME SCREEN -
INPUT 4 RENAME SCREEN -
INPUT 5 RENAME SCREEN -
INPUT 6 RENAME SCREEN -
INPUT 7 RENAME SCREEN -
INPUT 8 RENAME SCREEN -
GPI ALARM NAMES
INPUT 9 RENAME SCREEN -
GPI ALARM
REPORTING SETUP
GPI ALARM
REPORTING
MATRIX
- -
To Next Page
