CC4, T1 to T4, and 708 (which is HD only) Service 1 to 7. For more information on
Closed Captioning, see Closed Caption on page 80.
XDS
Located in the upper-left corner of the picture display is the Extended Data Services
(XDS) display when it is enabled in the PICTURE SETUP menu. The
Picture Setup/XDS menu is used to enable and disable XDS along with selecting the
information for line 6.
When XDS is selected, XDS data is decoded. There are five fixed lines (ID number,
Length of Time Elapsed, Program Name, Channel Info Network Name, and Content
Advisory), and one selectable line. Use the UP/DOWN NAVIGATION buttons to
select an item for the XDS.
The XDS selections are shown in Table 4-19. The bold items are always shown and
cannot be changed on the XDS display. All items are selectable except CHANNEL
INFO NETWORK NAME are available for line 6. For more information on XDS see
information on page 108.
Table 4-19. XDS Line Selections
Selection Selection Option Selection Option
ID NUMBER FUTURE CONTENT
ADVISORY
PSIP STRUCTURE CONTROL
LENGTH ELAPSED TIME FUTURE AUDIO SERVICES PSIP EIT DESCRIPTOR
PROGRAM NAME FUTURE CAPTION SERVICES PSIP DATA CARRIAGE
CHANNEL INFO NETWORK
NAME*
FUTURE COPY
MANAGEMENT
CHANNEL INFO CALL
LETTERS
TYPE FUTURE ASPECT RATIO CHANNEL INFO TAPE DELAY
CONTENT ADVISORY FUTURE COMPOSITE
PACKET 1
CHANNEL INFO TSID
AUDIO SERVICES FUTURE COMPOSITE
PACKET 2
MISC TIME OF DAY
CAPTION SERVICES FUTURE DESCRIPTION MISC IMPULSE CAPTURE ID
COPY MANAGEMENT PSIP MINOR CHANNEL MISC SUPPLEMENTAL DATA
LOCATION
ASPECT RATIO PSIP EVENT NUMBER MISC TIME ZONE
COMPOSITE PACKET 1 PSIP EVENT START OUT OF BAND CHANNEL
COMPOSITE PACKET 2 PSIP EVENT DURATION CHANNEL MAP POINTER
DESCRIPTION PSIP PROGRAM NAME CHANNEL MAP HEADER
FUTURE ID NUMBER PSIP PROGRAM TYPE CHANNEL MAP PACKET
FUTURE LENGTH ELAPSED
TIME
PSIP CONTENT ADVISORY NATIONAL WEATHER SVC
CODE
FUTURE PROGRAM NAME PSIP AUDIO SERVICES NATIONAL WEATHER SVC
MSG
FUTURE TYPE PSIP CAPTION SERVICES -
