TVM Series Installation and Operation Handbook 205
Copyright © 2008, Harris Corporation
Section 6 ♦ External Control
Using the Keyboard Commands
Table 6-1 lists the keyboard commands used for remote operation of a single TVM or
multiple TVM units with a USB keyboard connected. This table continues on the next
page.
Table 6-1. Keyboard Commands
Function Keystroke Description
Input A, a Selects INPUT A
Input B, b Selects INPUT B
Input Alt+A Selects INPUT A+B
Input C, c Selects INPUT C
Input D, d Selects INPUT D
Input Alt+C Selects INPUT C+D
Bypass Ctrl+B Toggles Bypass
EXT X, x Toggles Internal/External Reference
DISP J, j Toggles Frozen/Live Display
SDI K, k Toggles Frozen/Live data display
FULL F, f Toggles the selected quadrant full-screen/quad screen
MLT M, m Toggles Multi-mode/Normal-mode
UL 1 Selects the Upper Left Quadrant
UR 2 Selects the Upper Right Quadrant
LL 3 Selects the Lower Left Quadrant
LR 4 Selects the Lower Right Quadrant
WFM W, w Selects the Waveform display in the current quadrant
VECT E, e Selects the Vector display in the current quadrant
AUDIO U, u Selects the Audio display in the current quadrant
PICT I, i Selects the Picture display in the current quadrant
ALARM 9 Selects the Alarm display in the current quadrant
GAMUT G, g Selects the Gamut display in the current quadrant
TIMING T, t Selects the Timing display in the current quadrant
EYE Y, y Selects the Eye display in the current quadrant
OPT O, o Selects the Option display in the current quadrant
H H, h Selects the Horizontal Sweep mode
V V, v Selects the Vertical Sweep mode
MAG N, n Changes the horizontal magnification
STEP S, s Steps through the available gain selections
ZOOM Z, z Cycles through the Zoom modes
To Next Page
