External Control
206 TVM Series Installation and Operation Handbook
Copyright © 2008, Harris Corporation
Table 6-1. Keyboard Commands
Function Keystroke Description
1 F1 Selects Preset 1
2 F2 Selects Preset 2
3 F3 Selects Preset 3
4 F4 Selects Preset 4
5 F5 Selects Preset 5
6 F6 Selects Preset 6
7 F7 Selects Preset 7
8 F8 Selects Preset 8
▲ ↑ Up Navigation button
► → Right Navigation button
▼ ↓ Down Navigation button
◄ ← Left Navigation button
ENT Enter Enter button
SETUP Home Toggle Setup mode
EXIT End Exit menu
LINE L, l Toggle Line Select
PHASE P, p Toggle Phase control
CURS R, r Cycle through Cursor control
Curved Arrow CW > Curved Arrow knob clockwise rotation
Curved Arrow CCW < Curved Arrow knob counter-clockwise rotation
Curved Arrow Push / Curved Arrow knob push
↕ CW Page Up Vertical knob clockwise rotation
↕ CCW Page Down Vertical knob counter-clockwise rotation
↕ Push Insert Vertical knob push
↔ CW ] Horizontal knob clockwise rotation
↔ CCW [ Horizontal knob counter-clockwise rotation
↔ Push \ Horizontal knob push
Cold Start Ctrl+Alt+Del Cold Start
SpyderWeb II
The SpyderWeb II
™
Unattended Networked Monitoring System is used to monitor and
control TVM/TVM series devices from a single PC at a local or remote location. After
the installation of a Harris series device, the Ethernet port can be connected directly to
the Ethernet port of a PC.
SpyderWeb II has three basic functions:
• Remote control of the TVM/TVM
• Gather and organize alarm information generated by TVM/VTM
