External Control
210 TVM Series Installation and Operation Handbook
Copyright © 2008, Harris Corporation
Table 6-3. Web Remote Display Description
Key Field Description
6 VERTICAL BUTTONS
• Pressing the RIGHT ARROW button is similar to turning
the UP/DOWN knob to the right (up).
• Pressing the LEFT ARROW button is similar to turning the
UP/DOWN knob to the left (down).
• Pressing the PUSH button is similar to pressing the
UP/DOWN knob to perform the selected knob function
according to the menu or pane selected.
7 FAULT BUTTON The fault button is used to indicate when a fault occurs in the
TVM/TVM instrument. Pressing this button has no effect.
SNMP Communications
A Management Information Base (MIB) is an object database that can be monitored by
a Network Management System (NMS). The protocol standardized for communicating
MIB objects between an Agent and a Network Management System is the Simple
Network Management Protocol (SNMP).
An object in the Videotek TVM Series MIB represents each TVM Series parameter
and status, and each object can be referred to by a numeric designation called an Object
ID (OID). The root OID (Enterprise ID) for Videotek MIBs is 1.3.6.1.4.1.10039. The
full MIB tree is:
iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).10039.videotekMIB(1).vtRelease(10).vtTVMSeries(1)
Additionally, the TVM Series supports SNMPv1 and SNMPv2c traps. The TVM Series
MIB branch is called vtTVMSeries. The TVM Series MIB can be found on the SNMP
Support CD that is supplied with the instrument.
