TVM Series Installation and Operation Handbook 215
Copyright © 2008, Harris Corporation
Appendix A ♦ Specifications
Specifications are subject to change without notice.
Video Input Specifications: 3G/HD-SDI/SD-SDI Option
Item Specification
Digital inputs Two (2) dual standards inputs accepting Standard definition, SMPTE
259 MC formats or High definition SMPTE 292M, 372M, 424M,
425M-AB formats including: 525/59.94, 625/50, 1080i/60,
1080i/59.94, 1080i/50, 1080p/60, 1080p/59.94, 1080p/50, 1080p/30,
1080p/29.97, 1080p/25, 1080p/24, 1080p/23.98, 1080/30sF,
1080/29.97sF, 1080/25sF, 1080/24sF, 1080/23.98sF, 720p/60,
720p/59.94, 720p/50, 720p/30, 720p/29.97, 720p/24 Hz, 720p/23.98,
Format Standard Dual Link SMPTE 372M 4:4:4 (YC
BCR) 10 bit
Data rate 270 MB/s, 1.485 Gb/s, 2.97 Gb/s, auto detect; also div by 1.001 rates
Connectors 4 BNCs, active looping inputs
1 BNC monitor output
Level 800 mV, nominal source amplitude
Input cable equalization Up to 80 meters of Belen 1694A from 1.485 Gb/s to 2.97 Gb/s
Up to 100 meters of Belden 8281 at 1.485 Gb/s
Up to 250 meters of Belden 8281 at 270 Mb/S
Return loss ≤ -15 dB 5 MHz to 1.485 GHz
≤ -10 dB 1.485 GHz to 2.97 Gb/s
Monitor output Follows the selected digital input
Monitor output data rate 270 Mb/s, 1.485 Gb/s and 2.97 GHz
Monitor output connector BNC
Monitor output level 800 mV, nominal
Video Input Specifications: HD-SDI/SD-SDI Option
Item Specification
Digital inputs Two (2) dual standards inputs accepting Standard definition, SMPTE
259 MC formats or High definition SMPTE 292M, 372M, formats
including: 525/59.94, 625/50, 1080i/60, 1080i/59.94, 1080i/50,
1080p/30, 1080p/29.97, 1080p/25, 1080p/24, 1080p/23.98,
1080/30sF, 1080/29.97sF, 1080/25sF, 1080/24sF, 1080/23.98sF,
720p/60, 720p/59.94, 720p/50, 720p/30, 720p/29.97, 720p/24 Hz,
720p/23.98, Format Standard Dual Link SMPTE 372M 4:4:4 (YC
BCR)
10 bit
Data rate 270 MB/s, 1.485 Gb/s auto detect
Connectors 4 BNCs, Hi-Z passive looping
4 BNCs, active looping with option EYE-H
Level 800 mV, nominal
Input EQ Up to 100 meters of Belden 8281 at 1.485 Gb/s
Up to 250 meters of Belden 8281 at 270 Mb/S
Return loss ≤ -25 dB 100 kHz to 270 MHz
≤ -15 dB 5 MHz to 1.485 GHz
Monitor output Follows the selected digital input
