Specifications
216 TVM Series Installation and Operation Handbook
Copyright © 2008, Harris Corporation
Video Input Specifications: HD-SDI/SD-SDI Option
Item Specification
Monitor output data rate 270 Mb/s and 1.485 Gb/s
Monitor output connector BNC
Monitor output level 800 mV, nominal
Video Input Specifications: SD-SDI Option
Item Specification
Digital inputs Two (2) SMPTE 259-MC inputs, auto detect 525/59.94 and 625/50
Data rate 270 Mb/s auto detect
Connectors Hi-Z looping
4 BNCs, active looping, option EYE-S
Level 800 mV, nominal source amplitude
Input cable equalization Up to 250 meters of Belen 8281 at 270 Mb/s
Return loss ≤ -25 dB 100 kHz to 270 MHz
Monitor output Follows the selected digital input
Monitor output data rate 270 Mb/s
Monitor output connector BNC
Monitor output level 800 mV, nominal
Video Input Specifications: Analog Option
Item Specification
Analog inputs (C and D only) Two (2) NTSC/PAL composite video auto detect
Signal level 1V p-p
Input impedance Hi-Z, looping
Return loss ≤ -45 dB 100 kHz to 5 MHz
Reference inputs
Inputs Analog Blackburst, NTSC/PAL composite video, Tri-level sync auto
detect per SMPTE 274M
Levels 286 mV p-p ± 6 dB (Blackburst NTSC)
300 mV p-p ± 6 dB (PAL sync and burst)
600 mV p-p ± 3 dB (Tri level Sync)
Impedance
Selectable Hi-Z looping or 75Ω terminating
EYE and Jitter/Frequency Patterns
Item Specification
Eye display input Displays pre-equalized waveforms
EYE display types
• SD: 3 eye or 10 eye
• HD: 3 eye or 20 eye
EYE horizontal mag
• x1 - SD/HD = 3 eye displayed
- SD = 10 eyes displayed
