Specifications
218 TVM Series Installation and Operation Handbook
Copyright © 2008, Harris Corporation
DVI-I Output Specifications
Item Specification
Digital levels Per DDWG DVI rev 1
R, G, B levels Selectable 0.7 or 1V p-p, nominal
Pixel rate 65 Mp/s
Analog R,G,B impedance
75Ω
Horizontal sync Negative TTL pulse @ 48,363 Hz ± 1%
Vertical sync Negative TTL pulse @ 60.004 Hz ± 1%
Display accuracy
• ± 1% waveform
• ± 1° vector
• ± 37 ns Timing Digital
• ± 300 ns Timing Analog
Connector 29-pin DVI-I, female
Audio Options
Item Specification
Inputs (analog) Eight monophonic or four stereo channels, balanced or unbalanced
Maximum input level +24 dBu
Input connector 37-pin, D-sub, male
Impedance
> 20kΩ
Inputs (digital) Four AES/EBU serial digital pairs with input expansion option to
eight. Sixteen embedded audio channels, one Dolby® E or AC-3
stream
Input connectors Four or eight, BNC, female
Impedance
75Ω
Outputs (analog) Eight monophonic or four stereo channels, balanced or unbalanced,
follows selected audio input; Dolby inputs produce a two channel mix
down and/or full eight channel decode
Output level +24 dBu max
+6 to –50 dB adjustable
For digital audio, -20 dBFS produces a +4 dBu analog output level
Output connector 37-pin D-sub, male, shared with inputs
Impedance
10Ω unbalanced or 20Ω balanced, nominal
Signal to noise 100 dB (relative to signal level out of +24 dBu), typical
Outputs (digital) 4 AES/EBU and one Dolby
®
Digital, Dolby
®
E, or AES stream
embedded in the selected digital video source
Output connector Four shared with input
Impedance
75Ω, BNC, female
