Pinouts
230 TVM Series Installation and Operation Handbook
Copyright © 2008, Harris Corporation
Figure B-7. Ethernet RJ-45 Connector
Table B-6. Ethernet RJ-45 Connector Pinouts
Pinout Signal Pinout Signal
1 TX+ 5 N.C.
2 TX- 6 RX-
3 RX+ 7 N.C.
4 N.C. 8 N.C.
Figure B-8. USB Connector
Table B-7. USB Connector Pinouts
Pinout Signal
1 VCC
2 Data -
3 Data +
4 GND
5 GND
6 GND
