Creating an Event Table 187
Accessing the Program Event Screen
Press the Program Table function key to display the Program Event screen (Figure 10-8).
Figure 10-8 Gradient Controller Program Event Screen
In addition to the event table parameters, the Program Event screen displays four active
screen keys as described in Table 10-3.
Table 10-3 Program Event Screen Keys
Key Function
Clear Line Clears the line on which the cursor resides. The line remains in
permanent memory.
Clear Table Clears the entire table currently displayed on the screen and
returns the initial conditions line to default status. The table
remains in permanent memory until a new table is saved.
Save Saves the table currently displayed and erases the previous
values. You must save the table before leaving the Program
Event screen. Otherwise, any changes are lost.
Help Displays the Help screen associated with the Program Event
screen.
