SuperRack SoundGrid / User Guide
INDICATOR COLOR STATUS
SAMPLE RATE Green All devices are in sync
Red One or more devices are out of sync
REMOTE Green SuperRack is being controlled externally
Orange SuperRack is being controlled externally and console Touch and Turn is engaged
Red Something is wrong with the remote (e.g., disconnected)
MIRROR Green Mirroring is established
Red Mirroring is broken
CPU Indicators
The CPU indicator bars display the average CPU load of all cores of the primary server in the
server group. The number beneath also shows the average CPU load for that server. The small
line above the bar shows the peak load of the core with the highest CPU in that server group.
The color of the bar indicates server CPU status. CPU values are shown numerically in the Inventory page.
ETER
NDICATION
CPU load is less than 75%. It is likely that more plugins can be added.
YELLOW BAR
CPU load is 75%–85%. To avoid potential network overloads, you should
try to redistribute your processing load by moving or disabling certain
plugins.
ED
AR
The bar turns red when CPU exceeds 85%.
RAY
AR WITH
Server is not present or is malfunctioning.
ORANGE DSP LINE Displays peak CPU of the core with the greatest CPU load. The bar turns
red when peak load of the busiest core exceeds 85%.
