SuperRack SoundGrid / User Guide
57
Menu Item/Indicator Possibilities Function
Colors
Range of colors
Adds a color strip on edge of server icon to ease identification
of the device in the rack.
Information
Displays technical
information about the server
Use this information for troubleshooting and when speaking
with Waves Technical Support concerning server issues.
Remove
Remove the server from the
SuperRack.
Releases the server from the local host. It will then be
available to other hosts.
Server Status
Indicators on the icon describe server status.
Indicator
Possibilities
Function
Name Friendly name Double-click to rename the server. This name will appear
when you assign the server to racks.
Online/Offline
Green or red
Online (green) or Offline (red)
Server Temperature Degrees Fahrenheit or
Celsius
Indicates the temperature of the CPU. Select temperature
units in the Settings page.
CPU Meters Primary server only Average and Peak CPU values in numbers, and bars for
each core (see below).
⏐
(small vertical line) Redundant server only Identifies the second (redundant) server that will become
the primary server in the event of a fault.
