wtw inoLab Multi 9620 IDS User Manual

inoLab
®
Multi 9620 IDS Settings
ba77173e04 12/2017 103
Setting menu
TetraCon 925
Calibration /
Calibration data stor-
age / Display
- Displays the last calibration records
(max. 10)
Calibration /
Calibration data stor-
age / Output to USB
flash drive or printer
- Outputs the stored calibration data to
the USB-A interface (USB Host, e.g.
USB memory device/USB printer).
Calibration /
Calibration data stor-
age / Output to
RS232/USB
- Outputs the stored calibration data to
the USB-B interface (USB Device,
e.g. PC)
Calibration /
Calibration interval
1 ... 150 ...
999 d
Calibration interval for the IDS con-
ductivity sensor (in days).
The meter reminds you to calibrate
regularly by the flashing sensor sym-
bol in the measuring screen.
Reset - Resets all sensor settings to the deliv-
ery condition (see section 11.8.1
R
ESETTING THE MEASUREMENT SET-
TINGS, page 108).
Menu item Possible
setting
Explanation
Menu item Possible
setting
Explanation
Type Used measuring cell
Cal Measuring cells whose cell constant is
determined by calibration in the KCL
control standard solution.
Calibration range:
0.450 to 0.500 cm
-1
The currently valid cell constant is dis-
played in the status line.
man Freely adjustable cell constant in the
range 0.450 ... 0.500 cm
-1
.
Man. cell const. 0.450 ...
0.475 ...
0.500 cm
-1
Display and setting options for the
manually adjustable cell constant.
This menu item is only available when
Type man is set.
Temp. comp. (TC) /
Method
nLF
Lin
off
Procedure for temperature compen-
sation (see section 9.2 T
EMPERATURE
COMPENSATION, page 82).
This setting is only available for the
measured parameters, conductivity
(ϰ) and resistivity (ρ).
