inoLab
®
Multi 9620 IDS Data storage
ba77173e04 12/2017 115
12.3 Measurement data storage
12.3.1 Editing the measurement data storage
The contents of the manual or automatic measurement data storage can be
shown on the display.
Each of the measurement data memories has a function to erase the entire
contents.
Editing the data
storage
The memory is edited in the menu, Storage & config/ Data storage. To open the
Storage & config menu, press the <ENTER_> key in the measured value
display.
Open the manual or automatic storage directly with the <RCL> or <RCL_> key.
Settings
The settings are explained here using the manual data storage as
an example. The same settings and functions are available for the
automatic data storage and OUR/SOUR.
Menu item Setting/
function
Explanation
Data storage /
Manual data storage /
Display
- Displays all measurement datas-
ets page by page.
Further options:
 Scroll through the datasets
with <><>.
 Output the displayed dataset
to the interface with <PRT>.
 Quit the display with <ESC>.
Data storage /
Manual data storage /
Output to USB flash
drive or printer
- Outputs all stored measured val-
ues to the USB-A interface (USB
Host, e.g. USB memory device/
USB printer)
Data storage /
Manual data storage /
Output to RS232/USB
- Outputs all stored measurement
data to the USB-B interface (USB
Device, e.g. PC)
Data storage /
Manual data storage /
Erase
- Erases the entire manual mea-
surement data storage.
Note:
All calibration data remain stored
when this action is performed.
